TY-06

Inox-DEZHI: Are entirely made of stainless, They are especally used for systems that produce sanitary hot water producedby a boiler or from plate heat exchangers. They are excellent choices for situations that require high hygienic standards and aproduct life time that is practically limitless,The membrane is absolutely non-toxic and potable drinking and food grade. Thismodel of tanks is particularly useful for anti-water hammer effecting water systems,preventing vibrations or noises.They can also be used with reduced flow pumps.

Detail
THE ADVANTAGE OF TY-06 SERIES:
1.Stainless Steel body. It can adapt to all inds of bad outdoor weather and corrosive working environment.
2.It also can be easier for the high health level requirement of equipment . Meet the requirements of medicaldevice and drinking water.

3.lt also can meet requirement of customer. Production can replace the membrane and diaphragm style.

ltem
capacity
Max.Bars
D
H
Connector
Packing
TY-O6-36L-S 36 10/16 350 560 1" 35x35x56cm
TY-O6-50L-S 50 10/16 350 670 1" 35x35x67cm
TY-O6-60L-s 60 10/16 450 750 1" 45x45x75cm
TY-O6-80L-s 80 10/16 450 890 1" 45x45x89cm
TY-06-100L-s 100 10/16 450 940 1" 45x45x94cm
