DEZHI-TANK:With a replaceable membrane. This line is idealfor every modern installation and can be applied to any type of pump.The real volume of the pressure tank is greater than common tank. A compressor is not necessary since an air cushion, separated fromthe water by the membrane , maintains a constant pressure in the tank.The new type pressure tanks can also be provided with stainliesssteel flanges,applied for water booster system ,pumps, potable water storage.
ltem
|
capacity
|
Max.Bars
|
D
|
H
|
Connector
|
Packing
|
TY-07-180L | 180 | 10-16 | 560 | 1000 | 1" | 56x56x100cm |
TY-07-20OL | 200 | 10-16 | 650 | 970 | 1" | 65x65x97cm |
TY-07-30OL | 300 | 10-16 | 720 | 1260 | 1" | 72x72×126cm |
TY-07-50OL | 500 | 10-16 | 750 | 1500 | 1" | 75x75x150cm |
TY-07-750L | 750 | 10-16 | 750 | 1800 | 1" | 75x75x180cm |
TY-07-100OL | 1000 | 10-16 | 1000 | 1800 | 1" | 100x100x180cm |
TY-07-1500L | 1500 | 10-16 | 1100 | 2000 | 1" | 110×110x200cm |
